Three-Phase 250A Gray — PR ATS-250
Three-Phase 250A Gray — PR ATS-250
SKU: PR ATS-250
TRONIC Automatic Transfer Switch (ATS) controller uses microprocessor as its core which can precisely monitor voltage (loss of main power). The ATS will start functioning in the following circumstances; loss of power, over voltage, under voltage phase.
250A 4 pole automatic transfer switch unit which, in the event of a power outage, will automatically start a generator and transfer the load over to the Generator supply. When the Main supply returns to normal, the ATS will transfer the load back to the Main supply and shut down the generator.
250A 4 pole automatic transfer switch unit which, in the event of a power outage, will automatically start a generator and transfer the load over to the Generator supply. When the Main supply returns to normal, the ATS will transfer the load back to the Main supply and shut down the generator.
|
Item |
Particulars |
|||||
|
Item Description |
An Automatic Transfer Switch Panel is an interlocked isolator switch assembly automatically switch between main power supply and backup power supply in the event of a main power supply failure and recovery respectively. |
|||||
|
Functional components |
Automatic 4-Pole Motorized Isolator Transfer Switch |
|||||
|
Intelligent ATS Controller |
||||||
|
Rated Voltage |
380V |
|||||
|
Rated Current |
100A-1250A |
|||||
|
Control Voltage |
220VAC |
|||||
|
Features |
Readymade & simple, safe operation |
|||||
|
Shock-Resistant Enclosure |
||||||
|
Compact Design |
||||||
|
User-friendly operation |
||||||
|
Two-wire genset start/stop signal provision |
||||||
|
Incoming Supply phase monitoring and failure protection |
||||||
|
Elegant & sleek in appearance |
||||||
|
Manual operation possible (Physically on the switch or remotely from the panel controller) |
||||||
|
Power Terminations |
Top |
Main/Primary 3-Phase 4-Wire Input Supply |
||||
|
Backup/Secondary 3-Phase 4-Wire Input Supply |
||||||
|
Bottom |
Common 3-Phase 4 wire Output to Load |
|||||
|
Enclosure details |
Dimensions |
Current Rating (A) |
Width (mm) |
Height (mm) |
Breadth (mm) |
|
|
100 |
400 |
500 |
200 |
|||
|
150/160/200/250 |
600 |
600 |
300 |
|||
|
400/630 |
800 |
1000 |
400 |
|||
|
800/1250 |
800 |
1600 |
500 |
|||
|
Color |
RAL 7032 |
|||||
|
Coating |
Epoxy Polyester Powder Coating Textured Finish |
|||||
|
Mounting |
100A-630A |
Wall-mountable |
||||
|
800A |
Free-standing |
|||||
|
Cable entry |
Bottom |
|||||
|
Mechanical Impact Rating |
IK 10 |
|||||
|
Ingress Protection Rating |
100A-630A |
IP66 |
||||
|
800A |
IP55 |
|||||
|
Material & Coating |
Steel |
|||||
|
Operating environment |
Ambient Temperature |
-5°C to +35°C |
||||
|
Altitude |
|
|||||
|
Water and moisture |
Minimal water jets and Moisture |
|||||
|
Vibration & Gas |
No strong vibrations and no harmful gases that may corrode the metallic parts or the PVC enclosure and damage the insulation |
|||||
