Mccb Three-Phase 32A — MG 100L-0032-04

This 32A 4-Pole MCCB (Molded Case Circuit Breaker) provides reliable protection for low-voltage electrical systems in industrial, commercial, and large-scale residential applications. Designed to safeguard against overloads and short circuits, it ensures safe and stable operation in 3-phase power distribution networks. Built with a durable flame-retardant casing and compliant with IEC/EN 60947-2 standards, this MCCB is ideal for critical applications requiring dependable performance and easy maintenance.

Features:

•
  Rated Current (In): 32A


•
  Poles: 4


•
  Rated Insulation Voltage (Ui): 800V


•
  Impulse Withstand Voltage (Uimp): 8kV


•
  Rated Operational Voltage (Ue): 400/415V


•
  Rated Ultimate Short-Circuit Breaking Capacity (Icu): 18kA


•
  Rated Service Short-Circuit Breaking Capacity(Ics): 18kA


•
  Rated Short-Time Withstand Current (Ii): 400A


•
  Frequency: 50/60Hz


•
  Material: Flame-retardant casing


•
  Operating Temperature: -5°C to +40°C


•
  Compliance Standard: IEC/EN 60947-2


•
  Warranty: 1 Year

Applications:

•
  Industrial systems – for machinery and panel protection


•
  Commercial buildings – for load distribution and safety


•
  Renewable energy systems – for solar and wind power control


•
  Large residential complexes – for 3-phase incoming power protection


•
  Backup power systems – for generator and UPS integration
