Mccb Three-Phase 200A — MG 250L-0200-04

This 200A 4-Pole MCCB (Molded Case Circuit Breaker) provides reliable overcurrent and short-circuit protection for heavy-duty industrial and commercial applications. Built to IEC/EN 60947-2 standards with a high breaking capacity of 21kA, it ensures dependable performance and long-term durability. The 4-pole design offers complete protection across three phases and neutral, while adjustable thermal and magnetic trip settings allow precise calibration. Compatible with modular accessories and constructed from high-strength flame-retardant materials, this MCCB is ideal for large-scale electrical installations requiring stability, safety, and flexibility.

Features:

•
  Rated Current (In): 200A


•
  Poles: 4


•
  Rated Insulation Voltage (Ui): 800V


•
  Impulse Withstand Voltage (Uimp): 8kV


•
  Rated Operational Voltage (Ue): 400/415V


•
  Rated Ultimate Short-Circuit Breaking Capacity (Icu): 21kA


•
  Rated Service Short-Circuit Breaking Capacity (Ics): 21kA


•
  Rated Short-Time Withstand Current (Ii): 10 In


•
  Frequency: 50/60Hz


•
  Material: High-strength flame-retardant casing


•
  Operating Temperature: -5°C to +40°C


•
  Compliance Standard: IEC/EN 60947-2


•
  Warranty: 1 Year

Applications:

•
  Industrial facilities – for main distribution and heavy machinery protection


•
  Commercial buildings – for large load centers and electrical panels


•
  Backup power systems – for generator and UPS safety integration


•
  Renewable energy systems – for solar and wind power distribution


•
  Large residential complexes – for main 3-phase incoming power protection
