Mccb 4Pole 125A Three-Phase — MG 160L-0125-04

This 125A 4-Pole MCCB (Molded Case Circuit Breaker) is engineered to deliver dependable overcurrent and short-circuit protection for industrial and heavy-duty commercial electrical systems. Built to IEC/EN 60947-2 standards, it ensures reliable performance, high breaking capacity, and long-term durability. Its compact, space-saving design allows easy installation in electrical panels and switchboards, while compatibility with modular accessories such as auxiliary contacts and shunt releases adds flexibility for advanced applications.

Features:

•
  Rated Current (In): 125A


•
  Poles: 4


•
  Rated Insulation Voltage (Ui): 800V


•
  Impulse Withstand Voltage (Uimp): 8kV


•
  Rated Operational Voltage (Ue): 400/415V


•
  Rated Ultimate Short-Circuit Breaking Capacity (Icu): 21kA


•
  Rated Service Short-Circuit Breaking Capacity (Ics): 21kA


•
  Rated Short-Time Withstand Current (Ii): 10 In


•
  Frequency: 50/60Hz


•
  Material: Flame-retardant casing


•
  Operating Temperature: -5°C to +40°C


•
  Compliance Standard: IEC/EN 60947-2


•
  Warranty: 1 Year

Applications:

•
  Industrial plants – for machinery and panel protection


•
  Commercial facilities – for distribution panelboards and large load centers


•
  Renewable energy systems – for solar and wind integration


•
  Backup power setups – for generator and UPS connection


•
  Large residential complexes – for main 3-phase power safety
